Projection Welding Robotic Working Cell - M Series

Projection Welding Robotic Working Cell – M Series

Part:                  Engine support plate
Material :               Galvanized sheet
Process :          Projection welding
INQUIRY

Benefits of Projection Welding Robotic Working Cell – M Series

  • 10 minutes’ Program Set Up
  • 8 hours’ Mastering/Operating/Maintaining
  • Highly Standardized Components
  • Modular Design
  • 1 gripper is compatible with 2 products
  • Intelligent Data Analytics Software Service

  • 1. HRC650 Quality Monitor
  • 2. Conveyor
  • 3. Security fence
  • 4. Projection welder
  • 5. 3D Camera
  • 6. PLC control system
  • 7. Robotic + gripper
  • 8. Leakage detection
  • 9. Control cabinet
  • 10. HMI
  • 11. Finished Conveyor
  • 12. Feeding Conveyor
  • 13. Storage box

Application



Specification

Weldable Thermoformed sheet, galvanized sheet
Equipment color ±0.05~±0.5mm
Out-of-process Time 5s
Flexible Manufacturing  Multi-Model Series Production
Installation Method  Common Base Floor
Hardware  Robot*2, 3D Camera*1, 2D Camera*1,  Projection Welder*1
Software  Standard electrical drawings; Standard PLC recipe programme
Floor Space  5.0×4.3 m2
